Virtual Device

In scenarios such as device development, testing, and training, real device is required. However, real device is large, costly, and difficult to manage. Therefore, the need for device simulators has emerged. It can simulate the communication behavior of customer device (inverters) and provide an efficient and convenient solution for related work.
Virtual Device
  • ·Multi-Protocol Support·
  • ·Accurate Device Simulation·
  • ·Professional Test Environment·

Product Features

  • Multi-Protocol Support
    Multi-Protocol Support
    Supports Modbus, CRS, and other protocols, offering excellent compatibility.
  • Accurate Device Simulation
    Accurate Device Simulation
    Precisely simulates inverter communication behavior to efficiently resolve operational challenges.
  • Professional Test Environment
    Professional Test Environment
    Provides a simulation environment for testers to monitor data collector communication and optimize product performance.
  • Effective Solution Demonstration
    Effective Solution Demonstration
    Facilitates clear presentation of complete communication solutions between data collectors and inverters to clients and at exhibitions.

Product Parameters

Product ModelVirtual Device
Dimension125*80*38.5mm
Weight200g
Input voltageDC5V~12V
Operating current500mA (DC5V)
Operating temperature-40℃ ~ +85℃
Storage temperature-40℃ ~ +90℃
ReservedReserved antenna hole
COMFor RS-485/RS-232/TTL communication
DC5V-12VDC power input port
LAN----
Data input methodBluetooth
baud rate115200bps (default)
Hardware watchdogsupport
Bluetooth standardBLE5.0
Bluetooth distance20M (in an open environment)
Bluetooth local monitoring refresh rate1 second
Bluetooth local monitoring command cycle2 seconds
Operating frequency2.4GHz
Antenna typeOnboard antenna, IPEX (2nd generation), ANT BLE/BT
Antenna gain1.7dBi
Data rate1Mbps
Supported device protocolsModbus, CRS
Parameter configuration methodAT commands
Number of connected devices1 unit
Applicable PlatformsSmartLite

File Downloads

Applicable Scenarios

  • Street Light
  • UPS
  • BMS
  • Portable Energy Storage
  • Balcony Energy Storage
