| Product Model | WS 05-01 | WS 05-02 | WS 06-01 | WS 06-02 | WS 06-11 | WS 07-01 | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Basic parameters | Rated voltage | DC12V | DC12V | DC12V | DC12V | DC12V | DC12V | ||||||||||||
| Signal output | RS-485 | RS-485 | RS-485 | RS-485 | RS-485 | RS-486 | |||||||||||||
| Communication Protocol | Standard MODBUS | Standard MODBUS | Standard MODBUS | Standard MODBUS | Standard MODBUS | Standard MODBUS | |||||||||||||
| Baud rate | 9600 | 9600 | 9600 | 9600 | 9600 | 9601 | |||||||||||||
| Sensing parameters | Categories | Measurement range | Resolution | Accuracy | Measurement range | Resolution | Accuracy | Measurement range | Resolution | Accuracy | Measurement range | Resolution | Accuracy | Measurement range | Resolution | Accuracy | Measurement range | Resolution | Accuracy |
| Wind speed (measurement range) | 0～70m/s | 0.1m/s | ±（0.3±0.03V）m/s | 0～70m/s | 0.1m/s | ±（0.3±0.03V）m/s | 0～70m/s | 0.1m/s | ±（0.3±0.03V）m/s | 0～70m/s | 0.1m/s | ±（0.3±0.03V）m/s | 0～40m/s | 0.01m/s | ±0.5+2%FS | 0～70m/s | 0.1m/s | ±（0.3±0.03V）m/s | |
| Wind direction | 0～360º | 1° | ±3° | 0～360º | 1° | ±3° | 0～360º | 1° | ±3° | 0～360º | 1° | ±3° | 0～359 | 1° | ±3° | 0～360º | 1° | ±3° | |
| Atmospheric temperature | -50～+100℃ | 0.1℃ | ±0.3℃ | -50～+100℃ | 0.1℃ | ±0.3℃ | -50～+100℃ | 0.1℃ | ±0.3℃ | -50～+100℃ | 0.1℃ | ±0.3℃ | -40～+100℃ | 0.1℃ | ±0.5℃ | -50～+100℃ | 0.1℃ | ±0.3℃ | |
| Backplate temperature | -50～+100℃ | 0.1℃ | ±0.3℃ | -50～+100℃ | 0.1℃ | ±0.3℃ | -50～+100℃ | 0.1℃ | ±0.3℃ | -50～+100℃ | 0.1℃ | ±0.3℃ | -- | -- | -- | -50～+100℃ | 0.1℃ | ±0.3℃ | |
| Daily radiation | 0-2000w/m2 | 1w/m2 | ±7% | 0-2000w/m2 | 1w/m2 | ±7% | 0-2000w/m2 | 1w/m2 | ±7% | 0-2000w/m2 | 1w/m2 | ±7% | -- | -- | -- | 0-2000w/m2 | 1w/m2 | ±7% | |
| Atmospheric humidity | -- | -- | -- | -- | -- | -- | 0～100 RH % | 0.1 RH % | ±5 RH % | 0～100 RH % | 0.1 RH % | ±5 RH % | 0～100%RH | 0.1%RH | ±5%RH | 0～100 RH % | 0.1 RH % | ±5 RH % | |
| Tilt radiation | -- | -- | -- | -- | -- | -- | -- | -- | -- | -- | -- | -- | -- | -- | -- | 0-2000w/m2 | 1w/m2 | ±7% | |
| Air pressure | -- | -- | -- | -- | -- | -- | -- | -- | -- | -- | -- | -- | 10-1100hPa | 0.1hPa | ±1.5hPa | -- | -- | -- | |
| PM2.5 | -- | -- | -- | -- | -- | -- | -- | -- | -- | -- | -- | -- | 0-1000ug/m³ | 1ug/m³ | ±10μ g/m3 | -- | -- | -- | |
